Spacing
Filter media ISO Coarse 60%/G3, 2x20 m
Number: C15-350
Kundeservice
Mai Kaas-Hansen
Effective filter media for pre-filtration and coarse particles
| Number | C15-350 |
| Name | Filter media ISO Coarse 60%/G3, 2x20 m |
| Classification list |
|
Add to cart and request a quote to get a price.
SPACER
Your are not logged in
You have to log in to see our prices and to make purchases in the webshop.
Thermally bonded and rigid so it doesn't collapse
Easy to handle and install - no skin irritation
Fire tested – self-extinguishing according to several standards
Resistant to chemical effects from solvents and toxic fumes
Easy disposal as combustible material
Product description
Filter medium designed for pre-filtration or coarse filtration in air intakes or other general ventilation systems.
It is often used in the air intake for general ventilation in public buildings, offices, factories and all kinds of equipment.
A high dust capacity combined with a relatively low pressure drop makes the material very cost-effective and provides a long service life.
Specifications
| Applications | Comfort ventilation , Industrial and process ventilation |
| Width | 2000 mm |
| Length | 20000 mm |
| Thickness | 18 mm |
| Filterklasse | ISO 16890: Coarse 60% (EN 779: G3/G4) |
| Filter media | Synthetic |
| Brandklassificering jf. DIN 53438 | F1 |
| Relative humidity [%] | 100 |
| Operating temperature max. [C°] | 100 |
| Max. temperature short peaks [C°] | 120 |
| AirFlow [m³/t] | 5400 |
| Initial pressure drop [Pa] | 27 |
